Apex Swing 150
Home
/
Products
/
Apex Swing 150
Get a Quote
Back to Products
Apex Swing 150
NON-Thermal Break
Enjoy a wide field ofvision with our Hingeddoors, as the door leavesdo not obstruct the viewwhen opened, creating atransparent indoor space.
Product Overview
MD150 Single Hinged Door
MD150 Double Hinged Door
MD150Pivot Door
Pearl White
2721114G
Monument
2729066M
Black Mall
27219320
Other colours
Custom powder coating
Product Specifications
Glass Specifications
Available Glass Build-Up
5mm+12Ar+5mm
6mm+12Ar+6mm
8mm+9Ar+8mm
Glazing
5+12A+5
Visible Trans : 63%
Winter Nighttime U-Value : Winter Nighttime -1.85W/m²k
Summer Daytime U-Value : Summer Daytime – 1.81W/m²k
Glazing
6+12A+6
Visible Trans : 72%
Winter Nighttime U-Value : Winter Nighttime -1.85W/m²k
Summer Daytime U-Value : Summer Daytime – 1.83W/m²k
Glazing
8+12A+8
Visible Trans : 84%
Winter Nighttime U-Value : Winter Nighttime -2.73W/m²k
Summer Daytime U-Value : Summer Daytime – 2.72W/m²k
Hardware
Standard Hardware Reference
KINLONG
Optional Hardware Upgrades
Doric (Only for use without a flyscreen)
Maximum Performance
Water Tightness
+200Pa
Positive Pressure
Maximum pressure: +2.00 kPa
Negative Pressure
Maximum pressure: -2.83 kPa
Air Tightness
Under pressure difference of: +/-75Pa
Air Tightness
Allowed air infiltration rate: 25.945m3/hr
Product Highlights
Opening Diagrams
Application Scenarios
Suitable for various building and project types
Residential Buildings
Commercial Complexes
Office Towers
Hotels & Resorts
Schools & Universities
Hospitals & Healthcare
Shopping Malls
Villas & Townhouses
