VA-100 Double Hinge Door

Glass specifications:

5mm+18Ar+5mm

6mm+18Ar+6mm

8mm+12Ar+8mm

Glass Configuration:

Clear

Fluted Glass

Custom Coating Colors

Obscured Glass

Single Panel Silver Low-E

Double Silver Low-E

Ultra Clear

Single Panel Bule Low-E

Hardware:

KINLONG

Doric (Only for use without a flyscreen)

Standard Equipment

Optional Equipment

Water Tightness :
150Pa

Ultimate Pressure :
800Pa with no collapse

Air Tightness :
At +75 Pa: 2.14 L/s·m²
At -75 Pa: 2.10 L/s·m²
Overall Area: 6.36 m

GLAZING
5+18A+5
Visible Trans: 76%
U-Value:
Winter Nighttime -1.86W/m²k
Summer Daytime – 1.83W/m²k

8+12A+8
Visible Trans: 84%
U-Value:
Winter Nighttime -2.73W/m²k
Summer Daytime – 2.72W/m²k
